Stitch Welder Machine

In Stock

  • Duct Welding Machine
  • Control Panel for adjustable Welding speed
  • High quality welding rollers
  • Uses conducted copper wire
  • Fast, effective welding process

Description

Stitch Welder Machine / Duct welding machines are great for a nice, smooth finish to welded materials. This machine welds using conducted copper wire to form a smooth, neat weld without any damage to the galvanized surface. The welding machine uses high quality welding rollers to increase the service life and power efficiency, as well as ensure a fast, effective welding process. The duct welding machine carries out pulse and continuous welding, with an adjustable welding speed using the control panel.

Specifications
Diameter φ100-φ1000mm
Range Length 50-1000mm
Overlap 6mm
Thickness 0.4-1.2mm
Speed 2m/min
Copper Diameter φ2.0-2.2mm
Max Power 40kw
Weight 850kg+Chiller
Dimension 2300mm×800mm×1300mm
